Sodick TS Guide

  • TSG-OLD 3560337 K Guide for Sodick Small Hole Drilling Machine
  • TSG-OLD 3560337 K Guide for Sodick Small Hole Drilling Machine
  • TSG-OLD 3560337 K Guide for Sodick Small Hole Drilling Machine
TSG-OLD 3560337 K Guide for Sodick Small Hole Drilling MachineTSG-OLD 3560337 K Guide for Sodick Small Hole Drilling MachineTSG-OLD 3560337 K Guide for Sodick Small Hole Drilling Machine

TSG-OLD 3560337 K Guide for Sodick Small Hole Drilling Machine

  • Ref No.: TSG-OLD-030
  • OEM No.: 3560337 3560184
  • Size: OD=10mm,ID=0.30mm,L=23mm
  • Brand: Sodick
  • Product description: TSG-OLD 3560337 K Guide for Sodick Small Hole Drilling Machine,EDM Consumables,Power EDM
  • INQUIRY   EMAIL
Product Description:

Sodick TS Guide

OLd Type

Available ID=0.1mm-3.10mm

Body OD=14.0mm

Length L=24mm

Applicated to EDM Wire Cut Machine

Machine Model:

Sodick K1C, Sodick K1CN, Sodick K1CS, Sodick K2CN, Sodick K2PN, Sodick K3CN

Model NO.

ID (mm)

OEM NO.(5um)

OEM NO.20um

TSG-OLD-010

Φ0.10mm

-

-

TSG-OLD-015

Φ0.15mm

-

-

TSG-OLD-020

Φ0.20mm

-

-

TSG-OLD-025

Φ0.25mm

-

-

TSG-OLD-030

Φ0.30mm

3560184

3560337

TSG-OLD-040

Φ0.40mm

3560185

3560338

TSG-OLD-050

Φ0.50mm

3560186

3560339

TSG-OLD-060

Φ0.60mm

3560187

3560340

TSG-OLD-070

Φ0.70mm

3560188

3560341

TSG-OLD-080

Φ0.80mm

3560189

3560342

TSG-OLD-090

Φ0.90mm

3560190

3560343

TSG-OLD-100

Φ1.00mm

3560191

3560344

TSG-OLD-110

Φ1.10mm

3560192

3560345

TSG-OLD-120

Φ1.20mm

3560193

3560346

TSG-OLD-130

Φ1.30mm

3560194

3560347

TSG-OLD-140

Φ1.40mm

3560195

3560348

TSG-OLD-150

Φ1.50mm

3560196

3560349

TSG-OLD-160

Φ1.60mm

3560197

3560350

TSG-OLD-170

Φ1.70mm

3560198

3560351

TSG-OLD-180

Φ1.80mm

3560199

3560352

TSG-OLD-190

Φ1.90mm

3560200

3560353

TSG-OLD-200

Φ2.00mm

3560201

3560354

TSG-OLD-210

Φ2.10mm

3560202

3560355

TSG-OLD-220

Φ2.20mm

3560203

3560356

TSG-OLD-230

Φ2.30mm

3560204

3560357

TSG-OLD-240

Φ2.40mm

3560205

3560358

TSG-OLD-250

Φ2.50mm

3560206

3560359

TSG-OLD-260

Φ2.60mm

3560207

3560360

TSG-OLD-270

Φ2.70mm

3560208

3560361

TSG-OLD-280

Φ2.80mm

3560209

3560362

TSG-OLD-290

Φ2.90mm

3560210

3560363

TSG-OLD-300

Φ3.00mm

3560211

3560364

TSG-OLD-310

Φ3.10mm

-

-
